Properties
app.properties.Title |
|
|---|---|
| Use | EV Battery, Industrial, Inverters |
product.use.formulating.properties.Title |
|
|---|---|
| Linear CTE | 108 ppm/°C |
| Mixing Viscosity | 4000 mPa.s |
| One or Two Part | Two Part |
| Pot Life | 90 Minutes |
| Unprimed Adhesion - Lap Shear (Al) | 0.6 mPa |
typical.properties.Title |
|
|---|---|
| Color - Part A | White to Off-White |
| Color - Part B | Grey |
| Dielectric Strength | 0.0153 volts per mil v/mil |
| Durometer - Shore A | 40 |
| Elongation | 30 % |
| Heat Cure | 30 minutes @ 70°C |
| Specific Gravity | 2.25 g/cm3 |
| Tensile Strength | 101.526 psi |
| Thermal Conductivity | 1.6 W/m・K |
| Volume Resistivity | 4.9E + 14 Ω・cm |
